Standard SPEC :
PS. Please contact our Sales for Customized SPEC
TOP = -5 °C to 65 °C
| Parameter | 1 Channel ( 1A/1D ) | 2 Channel ( 2A/2D ) | |
| Operating Wavelength (nm) | 1260 to 1620 | ||
| Center Wavelength Accuracy (nm) | ± 0.5 | ||
| Channel Spacing (GHz) | 20nm | ||
| Channel Passband (@-0.5dB bandwidth) Min.(nm) | 1310 Express±50, Others>13 | ||
| Insertion Loss (dB) | Add/Drop Channel | <1.2 | <1.5 |
| Express Channel | <1.0 | <2.3 | |
| Add/Drop Channel Ripple (dB) | <0.3 | ||
| Isolation (dB) | Add/Drop Channel | >30 | >30 |
| Express Channel | >15 | >15 | |
| Insertion Loss Temperature Sensitivity (dB/°C ) | <0.005 | ||
| Wavelength Temperature Shifting (nm/ °C ) | <0.002 | ||
| Polarization Dependent Loss (dB) | <0.10 | <0.15 | |
| Polarization Mode Dispersion (ps) | <0.10 | ||
| Directivity (dB) | >50 | ||
| Return Loss (dB) | >45 | ||
| Power Handling (mW) | 300 | ||
| Operating Temperature °C | -5~+65°C | ||
| Storage Temperature °C | -5~+65°C | ||
| Operating Humidity (%RH) | <93 | ||
| Storage Humidity (%RH) | <93 | ||
1. Do you have any MOQ?
Ans : No, we did not set any MOQ unless for Special promotion item.
2. How can I pay you?
Ans : We accept Bank Wire Transfer, Paypal ( for <$1000 payment )
Please contact us for our Paypay account.
3. What is your warranty?
Ans : We offer basic 1 year warranty for all products.
4. Can I use your Transceiver module on Cisco or Alcatel-Lucent equipment?
Ans : Yes, we can offer Transceiver modules compatible on Cisco, Alcatel-Lucent, HP, Extreme…etc.
5. How about your lead-time?
Ans : For normal order, we can deliver in 1~2 weeks, for Hot selling products, we can deliver within 3 days.
